Manufacturing Facilities
Dust Free Environment
Positive air pressure and Epoxy flooring for dust free environment in entire plant.
Foil Winding Capability
Two PLC Based Fully Automac Parallel Foil winding Machines with Automac Argon or Helium Gas Based Brazing facility. Capacity to do 1200 mm foil winding.
PLC Based Autoclave
Programmable logic control Autoclave for Heang and fine Vacuum (0.1milbar) for drying of Core coil assembly suitable for 145KV system voltage.
- Hydraulic core liing tables - 5, 15 and 25 Ton.
- HV and LV Winding machines are micro-processor controlled with pneumac pressure arrangement and automac paper feeding and bending arrangement.
- Manufacturing flow in line with LEAN concept.
- Traceability, Idenficaon, stock integrated with SAP soware.
Oil Filling under Fine Vacuum
100% Transformer Oil filling under Fine Vacuum using a fully automac PLC controlled oil handling system with overhead oil storage tank for filtered oil.
- Fully automac Online oil mositure ppm measuring facility more suitable for 145KV System voltage.
- Separate systems for IEC specified, IS specified and Ester oil to avoid mixing.
- Material Storage and handling with Modern technology along with auto stacker
- In house insulaon cung area.
Low Frequency Heang (LFH) Drying of Large Transformers
- Short drying me that is 30-50% less than convenonal drying processes with hot oil circulaon and vacuum system results in shorter downme of the unit.
- High drying efficiency, reducing moisture to very low level.
- Onsite service eliminates the risks and costs associated with transportaon of Transformer.
- Moisture (water) removed can be measured.
COIL CASTING PLANT(VACUUM)
- Consistent Quality - Ensures uniform resin mixing, vacuuming, and casng for reliable product quality.
- Reduced Human Error - Minimizes dependency on operator skill, improving accuracy and repeatability.
- Beer Vacuum Impregnaon - Superior air removal ensures void-free casng, enhancing insulaon performance
- Improved Resin Mixing Ratio - Automac precision in resin-hardener mixing ensures beer mechanical and dielectric strength.
- Data Logging & Traceability - Allows recording of casng parameters for quality assurance and audits.
TESTING FEATURES
Impulse Generator
In-house Impulse Generator with Chopping 900 KVP / 90KJ
Automatic Testing Panels
Testing Laboratories
